- Fox H1 3.7kW Hybrid Inverter 1PH G2
#2: FE-H1-3.7-G2 Storage Systems - Hybrid Inverter
Fox H1 3.7kW Datasheet
Fox H1 3.7kW Manual
Fox H1 3.7kW Installer Guide
Fox H1 3.7kW G100 Certification
Fox Battery Sizing Guide
*Collections are not permitted due to health & safety regulations*
Features:
-
Easy Install
-
High Voltage
-
IP65 Rated
-
Remote Monitoring
- Dual MPPT - ensure optimal solar production
- High round-trip efficiency of 97%
With this single phase Hybrid/AC Inverter you can easily expand your system with up to seven batteries in series, with a maximum storage capacity of 33.24kWh.
Compatible with all Cube & EP5/11 batteries
Included:
Still Required:
-
a second CT if there's another generator set (i.e PV, wind or other).
-
a meter between inverter and incoming power connection point IF distance is more than 30m apart.
Compatibility:
-
FoxESS inverters compatible with Tigo optimisers
-
Fox ESS inverters are not compatible with SolarEdge or Huawei optimizers
Specs:
Weight: 22 kg
Rated Power: 3,680 W
Min PPT Voltage: 80 V
Max PPT Voltage: 550 V
DC Startup Voltage: 75 V
DC Shutdown Voltage: 600 V
Max Input Voltage: 600 V
Max DC Power (5 minutes): 5,500 W
Max AC Power (5 Minutes): 3,680 W
Surge AC Power (1 Second: 4,400 W
Max DC Current: 32 A
Max DC Inputs: 2
Has DC Fuses: 0
Connector: MC4
Included Connectors: 4
Euro Efficiency: 95.7 %
Transformer: None
MPPT Quantity: 2
Has Integrated DC Switch: Yes
Warranty: 5 years
Remember to register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page.
Please check the warranty document for more information.
