Solar Edge S500B Power Optimizer (33mm Depth)

Solar Edge S500B Power Optimiser (33mm Depth)

#2: S500-B2-MC4

S500B2 Datasheet

S500B2 Product Update

S500B2 Installation guide

S500B2 Warranty

Minimum order: 4 Units

• Specifically designed to work with SolarEdge residential inverters
• Mitigates all types of module mismatch loss, from manufacturing tolerance to partial shading
• Faster installations with simplified cable management and easy assembly using a single bolt
• Detects abnormal PV connector behavior, preventing potential safety issues
• Module-level voltage shutdown for installer and firefighter safety
• Flexible system design for maximum space utilization
• Compatible with bifacial PV modules
• Superior efficiency (99.5%)

Specs

Weight: 0.65 kg
Min PPT Voltage: 12 V
Max PPT Voltage: 105 V
DC Startup Voltage: 8 V
DC Shutdown Voltage: 8 V
Max Input Voltage: 80 V
Max DC Power: 500 W
Max AC Power (5 Minutes): 0 W
Surge AC Power (1 Second): 0 W
Max DC Current: 15 A
Max DC Inputs: 1
Has DC Fuses: 0
Connector: MC4
Included Connectors: 1
Euro Efficiency: 0 %
Transformer: N/A
MPPT Quantity : 1
Has Integrated DC Switch: No
Warranty: 25 years
